Daehyup Billyetex

 Exteror Deck Coverings

BILLYTEX EP-100

- BILLYTEX EP-100 is a deck covering material made by two-part epoxy type. And it has possible to make magnificent appearance due to wide range of color selection.
BILLYTEX EP-100 has generally used it wet area on ship. Also it has excellent characteristicts as water proof, adhesivw property, wear resistance, chemical resistance and acid resistance. It also sarisfies 2010 FTP CODE PART5.

Characteristics

- Magnificent appearance due to wide range of color selection.
- Excellent adhesive component anti-corrosion effect.
- High density and anti-abrasion.
- Chemical-resistance nature.
- Easy repair and maintenance
- Easy installation and outstanding solidity.

Application

-Floors in buildings, laboratory and machinery room, anti-chemical floors such as those of chemical factory and refrigerator. Accommodation and exposed decks.

Packing unit and quantity
Process
Material

Standard
thickness

Quantity (kg/㎡ )

Remark

Primer
coat

Resin
0.5mm
0.3
2kg
Hardener
0.8kg

Mortar
coat

Resin
4mm
1.13
2.4kg
Hardener
0.87kg
Color sand
6.2
18kg

Top
coat

Resin
0.5mm
0.5
2kg
Hardener
1.09kg
Technical Data
Unit
Result
Note
Basis
-
Silica sand, Color sand. Epoxy
Density
g/㎤
Approx. 1.8 (applied)
Potlife
min
40-60
at +25℃ & 65% RH
Curing time
hours
18-24
at 25℃
Compression strength
MPa
78.6
KS F 4041
Flexural strength
MPa
29.5
KS F 4041
Wear resistance

AR1
BS EN 13892-4
Adhesion strength
MPa
2.6
KS F 47 16
Typical Application
